Double Spooler For Intermediate Wire Drawing Machine Max No Drafts 17

Product Categories

NEWLEAD WIRE AND CABLE MAKING EQUIPMENTS GROUP CO.,LTD

Contact Now

Name: Double Spooler For Intermediate Wire Drawing Machine Max No Drafts 17
Brand: NEWLEAD
Price: 1 USD

Place of Origin : Jiangsu, China (Mainland)

Brand Name : NEWLEAD

Model Number : 17DST

Price : Negotiation | 1 Unit/Units 17d wire drawing machine (Min. Order)

MOQ : 1 Unit/Units

Certification : ISO CE

Supply Ability : 30 sets in 3 months

Delivery Time : 60 days

Packaging Details : wooden pallet or by wooden box

Usage : Winding

material : soft Cu

inlet : 2.5-3.5

outlet : 0.4-1.8

Drafts : Max 17

Speed : Max 1800MPM

Contact Now

Double spooler for Intermediate wire drawing machine Max No drafts 17

Design:

pintle-type double spooler
fully automatice wire changeover principle for continuous operation
fully automatic spool change
conveyors for empty and full spools in different lenghts

Increase in quality:

highly reliable wire changeover
ceramic-coated wire guide pulleys for high wire surface quality and long service lives

Increase in productivity:

fully automatic spool change for continuous production operation
high machine availability due to mini- mized changeover and maintenance time

Energy and cost efficiency:

• maintenance-free three-phase AC drives

machine	17DST
inlet diameter(mm)	Φ2.5-3.0
outlet diameter(mm)	Φ0.4-φ1.8
drawing line speed(MPM)	1500
drawing dies No./Max.	17
slip ratio of m/c	20%
fix speed capstan slip ratio	15.5%
capstan	tungsten
capstan dia.(max.)(mm)	Φ250
fix speed capstan dia.(mm)	φ 250
frame	weld,two conjunctions
main motor	45KW,ACmotor
spooler motor	15KW AC motor
revise system	PID synchronous spooler
power control	AC motor inverter control
transmission type	gear
Payoff method	over head
traversing unit	decelerate motor
tension control	pneumatic balance by swing arm
lubrication system of wire drawing	all immerse type
suitable diameter of apool (mm)	PND630
capacity for wire receiving (kg)	200-500
power source	380V.( OEM)
brake	pneumatic

Double Spooler For Intermediate Wire Drawing Machine Max No Drafts 17
